2500l
SDPY Brewtech
1. Stand type
2. Total volume: 3300L, effective volume: 2500L,
3. Size: Φ1700×H3150mm
4. Double wall, with dimple plate cooling jacket; cooling area 3.6 m2,
5. Insulation thickness: 100mm
6. Inner container thickness: 3mm, tank cladding 2mm.
7. Tank cladding surface brush finished, inner container plate polish to ≤0.6um
8. With pressure gauge, liquid meter, sample valve, breather valve, and matched valves, fittings. food sanitary grade
9. With mechanical type pressure regulator
10. With hops dosing inlet
11. With beer outlet on tank undercone side part
12. with drain outlet on tank bottom, add a clamps for move out the drain outlet freely
13. With apple type rotary spray ball
13. Conical bottom, domed top
14. With side manhole in front of tanks,
15. With all valves matched
16. With 60degree under cone angle
1. Stand type
2. Total volume: 3300L, effective volume: 2500L,
3. Size: Φ1700×H3150mm
4. Double wall, with dimple plate cooling jacket; cooling area 3.6 m2,
5. Insulation thickness: 100mm
6. Inner container thickness: 3mm, tank cladding 2mm.
7. Tank cladding surface brush finished, inner container plate polish to ≤0.6um
8. With pressure gauge, liquid meter, sample valve, breather valve, and matched valves, fittings. food sanitary grade
9. With mechanical type pressure regulator
10. With hops dosing inlet
11. With beer outlet on tank undercone side part
12. with drain outlet on tank bottom, add a clamps for move out the drain outlet freely
13. With apple type rotary spray ball
13. Conical bottom, domed top
14. With side manhole in front of tanks,
15. With all valves matched
16. With 60degree under cone angle
