60BBL stainless steel beer fermenters

No.

ITEMS

SPECIFICATION

1

Volume

60bbl

2

size

Φ2000×H4260mm   (customize, can be design base on customer place height and door size)

3

Effective     volume

60BBL

4

Total     volume

80BBL

5

heating     area

8.2m2

6

cooling     way

with     glycol cooling jacket, tank body and tank bottom part both have

7

washing     way

Apple     type CIP spray ball(rotary); In the center of the inside tank

8

beer   out   way

with     beer outlet and drain valve

9

welding     way

Perfect     argon arc welding, Welds are smooth and flat and the arrangements of   welds   have to be not more than Ra 0.6 μm. Inside and outside polishing     processing, No welding dead corner.

10

control     way

single     control for unit tank

11

temperature     control ways

Displace     the temperature directly on the tank, display temperature from   intelligent   data meter

12

Temperature     Measurement ways

Temperature     sensor PT100, temperature display by intelligent data meter or PLC   control

13

Pressure     control ways

CO2     pressure regular valve

14

tank   cladding   material

Stainless   Steel   SUS304

15

Material     of tank cladding

Stainless   Steel   SUS304

16

Material     of inner container

Stainless   Steel   SUS304

17

surface     of out cladding/surface treatment

surface     brushed finish

18

surface     of inner container

Polishing   precision≤0.6µm

19

tank     cladding Thickness

2mm(customize)

20

Inner   tank   material

3mm(customize)

21

top     Seal head

domed     top

22

head     thickness

3mm

23

under     cone

conical     cone

24

cone     angle

60     degrees;

25

Insulation   layer   material

Protected   by polyurethane

26

Insulation   layer   Thickness

80   mm (customize, can   design as per requirement)

27

tank   pressure

28

test   pressure

0.2Mpa   (customize, can   design as per requirement)

29

work   pressure

0.1-0.2Mpa   ((customize, can design as per requirement)

30

Manhole

side   manhole

31

valves     and fitting

Matched
    valves including：
    1)breather valve
    2)drain valves
    4)sample valves
    5)beer outlet valves

32

electric     instruments

relief   valve; intelligent data meter

33

Parts

Food   grade;

34

Packaging     Detail

export     standard, maximum protection, including: Wooden case, plastic film,   bubble   film etc.

35

Certification:

CE   and ISO.

36

Graphic   measurement

JUST   FOR REFERENCE
