Flash pasteurizer, Instant Sterilization Equipment

SDPY Brewtech flash pasteurizer machine, using three-stage heat exchange combination structure to achieve beer preservation, it is a necessary part of aseptic filling. The pumps, piping and valves all are stainless steel, durable.

Availability:

Quantity:



Inquire Add to Basket

Model:
500L/H, 1000L/H, 2000L/H, 3000L/H, 4000L/H, 5000L/H, 6000L/H, 7000L/H, 10000L/H.
Brand:
SDPY Brewtech

Product Description

SDPY Brewtech flash pasteurizer machine, using three-stage heat exchange combination structure to achieve beer preservation, it is a necessary part of aseptic filling. The pumps, piping and valves all are stainless steel, durable.

500L/H, 1000L/H, 2000L/H, 3000L/H, 4000L/H, 5000L/H, 6000L/H, 7000L/H, 10000L/H.

We have a wide range capacity flash pasteurizer： 500L/H, 1000L/H, 2000L/H, 3000L/H, 4000L/H, 5000L/H, 6000L/H, 7000L/H, 10000L/H.

Principle of operation

The beer ready to sterilize passes through the high-pressure beer pump into the plate heat exchanger, Pre-heated up to 65℃,Again heated by 85℃ of hot water to 75℃,After being section for 30 seconds，It can reach a pasteurized unit value of 25Pu.Then cool down to 12℃ through the plate heat exchanger，Finally, enter the cooling system and cool down to 2℃，Then enter the buffer tank for subsequent filling.

When the sterilization temperature is below the process requirements (set to 75℃), it can enter the cycle state automatically, When the sterilization temperature rises to 75℃,Automatic shut the circulation valve for 1 minute. Open the wine pneumatic butterfly valve, ensure the quality of sterilization. When the other control parameters exceed the set value, the equipment alarms and stops automatically.

Feature

● Three-stage heat exchange combination structure, good heat exchange effect, and energy saving

● Instantaneous sterilization, to ensure that the beer flavor, nutrition, the minimum degree of loss

● Valves, pipes and pump body are made of food-grade stainless steel to ensure beer hygiene and safety

● Flow meter, pneumatic valve are imported brand, with Siemens display, can each link to be highly monitored

● Using PID closed-loop adjustment mode, cooperate with CI system, fully automatic cleaning of the equipment

● Low structural tendency, small volume, small heat loss, low maintenance price, very high sex price.

Heating form: steam heating;

Refrigerant temperature: -5℃~-2℃；

Refrigerant pressure: 0.1~0.3Mpa;

Cold water pressure: 0.2~0.3Mpa;

Steam pressure: 0.2~0.5Mpa;
